Siemens System 3 User Manual

32
1. System 3™ Control Panel/Enclosures
Model No. Part No. Description Catalog No.
ED-32DPSM 500-686192 Marine Mounting Kit (4 Shock) 3325
ED-33DPSM 500-686193 Marine Mounting Kit (6 Shock) 3325
ED-35DPSM 500-686194 Marine Mounting Kit (10 Shock) 3325
3. System 3™ Accessories
Model No. Part No. Description Catalog No.
PTR-1 500-186248 Power Transfer Relay Manual
RL-6 500-616120 Remote Alarm Lamp 8010
RL-30 500-390671 Remote Lamp 8011
RL-40 500-390672 Remote lamp 8011
RLP-4 500-616141 Remote Indicator 8012
RLP-8 500-616142 Remote Indicator 8012
RLP-12 500-616143 Remote Indicator 8012
RTA-38 500-684960 Remote Trouble / Alarm ---
EL-30/31 500-621296 EOL Device ---
Model No. Part No. Description Catalog No.
AD-30S 500-645050 Annunciator Driver (Supervised) —
AE-30U 500-884320 Alarm Extender Module 3129
BC-35 500-884857 Battery Charger 3177
BE-35 500-884859 Battery Charger Extender 3177
BK-33 515-087135 Battery Module for BT33/34 3351
BT-33 175-387140 5 AH Battery Package Manual
BT-34 175-387141 10 AH Battery Package Manual
BTX-1 175-083897 Battery Complement 28/Amp/HR 3361
CP-35 500-884879 Control Module 3060
DM-31 500-821940 Distribution Module Manual
MC-30 500-821710 Master Code Module 3163
MM-35 500-884860 Meter Module 3355
PM-31 500-821750 Program Module 3169
PM-32 500-822170 Program Module 3169
PS-35 500-884950 Power Supply - 10 Amp 3061
RC-30U 500-885460 Confirmation Module 3167
RM-30RU 500-884340 Releasing Device Module 3325
RM-30U 500-884330 Releasing Device Module 3062
SM-30 500-821670 Switch Module 3162
SR-30 500-821620 Dual Relay Module 3121
SR-32 500-887690 Multiple Relay Module 3125
SR-35 500-887690 Multiple Relay Module 3130
TC-30U 500-885260 Battery Transfer Module 3132
TL-30U 500-885330 Time Limit Module 3166
ZN-31U 500-886170 Dual Contact Zone 3108
ZN-34UA 500-894213 Dual Zone Supervised 3109
ZN-34US 500-895357 Dual Zone Supervised 3109
ZS-30 500-680242 Intrinsically Safe Zone 3105
ZU-35TS 500-885420 Dual Zone with Test Switches 3107
2. System 3™ System Modules
“ --- ”:
Catalog Sheet is not available. However, an instruction sheet is provided with the shipped equipment.
