23
Interface description
RS232 interface The RS232 interface is the interface for the
application software and the connection to
the PC. The customer application
communicates with the TC35 Terminal or
the TC35 GSM engine by means of
ATcellular commands. The RS232 interface
is implemented as a 9-pin D-Sub socket with
a screw fitting.
RS232 interface – 9-pin D-Sub
9
1
2
3
4
5
6
7
8
