On our own account
Dear Customer. The Instrument panel of this vehicle is fitted with
an electronic speedometer, the E-Tacho 1323. Its modular layout
allows a customer-specific design of this device. This may lead to
possible differences between these operating instructions and the
fittings of your E-Tacho.
Indicating elements and controls
(1)
Speed indication
– Speed range: from 80 km/h – 180 km/h
(2)
LC Display
– 7-Digit display of total distance travelled, the last digits
showing 100 m
– In addition, either the time or the daily kilometres driven
are shown in the lower line of the display (option).
(3)
Setting knob
With this knob you may ...
– switch from time to daily kilometres,
– reset the trip odometer,
– set the time of day (with device type 1323.02 only).
(4)
Function monitoring
This LED will light up if a component of the tachograph
system is not in proper working order.
© Copyright Siemens AG 9
