Ionics Instruments 2004 Page D - 1 DLM 30007-08 Rev. A
APPENDIX D – BINARY INPUT MODULE – FLOW SWITCH
This appendix describes the activities required to install the flow switch and
firmware 2.11 CBI in all 800 series TOC analyzers.
The Turbo firmware 2.12 CTB or later has incorporated the INPUTS menu
item. Follow these instructions except skip the firmware installation
steps.
The materials and tools needed for this procedure are:
7/16” open-end or adjustable wrench
½” open-end wrench
Flat head screwdriver
Phillips head screwdriver
Scriber
Teflon tape
WARNINGS
A 60-micron filter must be used to ensure proper operation of the flow switch.
Do not overtighten any fitting.
Switch orientation should be no more than 15° from vertical alignment.
Do not install units near ferrous metals, magnets or electromagnetic fields.
