Specifications
MODEL
48V60
48V80
48V100
48V120
Solar System Voltage
12V/24V/48V
Electrical
PV operating voltage
15 ~50Vdc@12V
30~100Vdc@24V
60~145Vdc@48V
15 ~50Vdc@12V
30~100Vdc@24V
60~145Vdc@48V
15 ~50Vdc@12V
30~100Vdc@24V
60~145Vdc@48V
15 ~50Vdc@12V
30~100Vdc@24V
60~145Vdc@48V
Max. PV open circuit voltage
150Vdc
150Vdc
150Vdc
150Vdc
Max. PV input power
1000W@12V
1250W@12V
1500W@12V
1750W@12V
2000W@24V
2500W@24V
3000W@24V
3500W@24V
4000W@48V
5000W@48V
6000W@48V
7000W@48V
Number of MPPT trackers
1
1
2
2
Max. charging current
60A
80A
100A
120A
Self Consumption
3W
3W
5W
5W
MPPT Efficiency
99.5%
99.5%
99.5%
99.5%
Conversion Efficiency
97.5%
97.5%
97.5%
97.5%
Protection
High voltage, high temperature protection
Battery Charging
Battery Type
Sealed, AGM, Gel, Flooded, Lithium, User define
Charging Algorithm
Bulk, Absorption, Float, Equalize
Bulk charge voltage
Sealed:14.4V AGM Gel:14.1V Flooded:14.6V User define:12-14.6V
(For 24V system, total voltage*2; for 48V system, total voltage*4)
Float charge voltage
Sealed/Gel/AMG:13.7V Flooded:13.6V User define :12-14.6V
(For 24V system, total voltage*2; for 48V system, total voltage*4)
Low DC Warning SOC (Only Li)
Low DC Cut-off SOC+5%
Low DC Warning Return SOC
(Only Li)
Low DC Cut-off SOC+15%
Temperature compensation
-5mV/℃with BTS(Optional)
Communication
Communication Port
USB
Mechanical
Net weight
3KG
3.2KG
4KG
4.2KG
Dimensions
295*180*100
295*180*100
320*200*105
320*200*105
Cooling
Fan cooling
Enclosure
IP20
Environment
Ambient Temperature
-20~55℃ ( Derating from 45℃)
Storage Temperature
-40℃~+60℃
Humidity
100% non-condensing

Sigineer Power 48V60 Specifications

General

Brand	Sigineer Power
Model	48V60
Category	Controller
Language	English
