Information on this Manual
Validity
This manual is valid for the following devices:
MPPT solar charge controller 48V60
MPPT solar charge controller 48V80
MPPT solar charge controller 48V100
MPPT solar charge controller 48V120
Scope
This manual describes the assembly, installation, operation and troubleshooting of this unit. Please read this manual
carefully before installations and operations.
Target Group
This document is intended for qualified persons and end users. Tasks that do not require any particular qualification
can also be performed by end users. Qualified persons must have the following skills:
Knowledge of how a solar charge controller works and is operated
Training in how to deal with the dangers and risks associated with installing and using electrical devices
and installations
Training in the installation and commissioning of electrical devices and installations
Knowledge of the applicable standards and directives
Knowledge of and compliance with this document and all safety information
Safety Instructions
WARNING: This chapter contains important safety and operating instructions.
Read and keep this manual for future reference.
1.
CAUTION – Only qualified personnel can install this device with battery.
2.
Before using the unit, read all instructions and caution marks on the unit, understand the batteries and all
appropriate sections of this manual.
3.
CAUTION --To reduce risk of injury, charge only deep-cycle lead acid type rechargeable batteries. Other types
of batteries may burst, causing personal injury and damage.
4.
NEVER charge a frozen battery.
5.
Do not disassemble the unit. Take it to a qualified service center when service or repair is required. Incorrect
re-assembly may result in a risk of electric shock or fire.
6.
To reduce risk of electric shock, disconnect all wiring before attempting any maintenance or cleaning. Turning
off the unit will not reduce this risk.
7.
Be very cautious when working with metal tools on or around batteries. A potential risk, such as dropping a tool
to spark or short circuit batteries or other electrical parts, could cause an explosion.
8.
Please strictly follow installation procedure when you want to disconnect terminals. Please refer to
INSTALLATION section of this manual for the details.
9.
Warning!! Only qualified service persons are able to service this device. If errors still persist after following
troubleshooting table, please send this solar charge controller back to local dealer or service center for
maintenance.
