Press Utility → Output → Load, then use the softkeys, number keys or
knob to change the parameter value; or continue pressing the
corresponding output key for two second to switch between High
Impedance and 50 Ω.
High Impedance: display HiZ.
Load: display impedance value (the default is 50 Ω and the range is 50 Ω to
100 kΩ).
Note: This setting does not actually change the instrument’s output
impedance of 50 Ω but rather is used to maintain amplitude accuracy into
different load values.
Output ----Channel output state.
After pressing corresponding channel output control port, the current
channel can be turned on/off.
5. LAN Status Icon
The SDG2000X will show different prompt messages based on the current
network status.
This mark indicates LAN connection is successful.
This mark indicates there is no LAN connection or LAN connection is
unsuccessful.
6. Mode Icon
The SDG2000X will show different prompt messages based on the current
choosing status of the mode.
This mark indicates current mode is Phase-locked.
This mark indicates current mode is Independent.
7. Menu
Shows the menu corresponding to the displayed function. For example,
Figure 4 shows the parameters of “AM modulation”.
8. Modulation Parameters Area
Shows the parameters of the current modulation function. After selecting
the corresponding menu, use number keys or knob to change the
parameter value.
