SDG2000X_ServiceManual_SM
0202X-E01B.doc
XII
The Rear Panel at a Glance
WARNING: For protection from electric shock, the grounding power cord must
not be defeated. If only a two-contact electrical outlet is available, connect the
instrument’s chassis ground screw (see above) to a good earth ground.
Aux In/Out
10 MHz Clock Input/Output
Earth Terminal
LAN Interface
USB Device
AC Power Supply Input
Counter
Aux In/Out
