Overview of this Document
This document is for the SDG2000X series arbitrary waveform generator,
which will be mostly referred to “the generator” for short in the following text.
The main contents described in this manual are:
The SDG2000X Series Generator at a Glance
This part introduces the main technology characteristics for the SDG2000X
generator.
The Front Panel at a Glance
This section introduces briefly all of the buttons and the knob on the front
panel.
The Rear Panel at a Glance
This section introduces the ports for easy communication on the rear panel.
Specification
Chapter 1 lists the generator’s specifications.
Quick Start
Chapter 2 describes prepare the generator for use and helps you get familiar
with a few of its front-panel features.
Performance Verification
Chapter 3 provides Performance Verification
Assembly Procedures
Chapter 4 provides disassembly procedures to help in gaining an
understanding of the structure of the generator in preparing to install or replace
any needed modules, or troubleshoot faults that might be encountered during
operation.
Troubleshooting
Chapter 5 provides troubleshooting procedures for the internal circuit boards,
as well as a quick guide for solving general problems. Before any operation,
please read the ESD Precautions to avoid personal injuries or damages to the
generator.
Maintenance
Chapter 6 provides information on maintenance, daily care and unpacking
inspection of the instrument. The contact information is included at the end of
To Next Page
