SDG2000X_ServiceManual_SM0202X-E01B.doc
IX
The Front Panel at a Glance
3. Touch Screen Display
10. Waveform Option
Area
4. Numeric Keyboard
5. Knob
1.Power Switch
11. Menu Keys
2.USB Host
6. Arrow Keys
7. CH1/CH2 Control/Output Port
9. Function Keys
8. Channel Select Key
