SVA1000X User Manual 109
Data of Trace C
Syms/Errs
Format of Trace C
Log Mag
Data of Trace D
IQ Meas Time
Format of Trace D
I-Eye
Properties
Eye Length
2
Symbol Table
Hex
Marker
Select Trace
A
Select Marker
1
Marker Type
Normal
Relative To
2
Couple
Off
Meas Setup
Format
16QAM
Symbol Rate
10 ksps
Points/Symbol
4
Meas Length
128
Filter Setup
Meas Filter
Sqrt Nyquist
Ref Filter
Nyquist
Alpha/BT
0.35
Filter Length
64
Statistic
Statistic
Off
Average
Off
Avg Times
10
6.4.2 Couple
Set related parameters according to the coupling relationship.
Auto all: Set Related parameters automatically according to the coupling relationship.
1. Freq step
Freq step has a coupling relationship with RBW at the zero span, when in none-zero mode, Freq step
have coupling relationship with Span. please refer to the introduction of the "Freq Step".
2. Attenuation
Input attenuation has coupling relationship with Ref Level and the preamp. Please refer to introduction
of "amplitude".
3. RBW
