Attaching the bracket
Attaching the MC 1812 and initial use
www.sigmasport.com MC 1812 Page 7
MC 1812
2 Attaching the MC 1812 and initial use
Detailed attachment information can be found in the quick start guide provided.
2.1 Attaching the bracket
− Attachment to the handlebars or cockpit
− Remove the adhesive tape from the bracket (permanent attachment)
− The bracket can be attached using either cable ties (permanent attachment)
or the O-rings.
2.2 Attaching the sensor
− Use the cable ties to attach the sensor to the front wheel fork.
− Ensure that the sensor cable cannot rub anywhere.
− The sensor cable must have enough play when turning the handlebars.
2.3 Connecting the sensor to the bracket
− Guide a sensor cable contact head from below into the left, lower section of
the bracket.
− Insert the cable with the contact head into the opening from the top.
− Press the contact head into the bracket.
− Now guide the other end of the sensor cable into the right, lower section of
the bracket from below.
− Insert the cable with the contact head into the lower of the two openings
from above.
− Press the contact head into the bracket.
− The sensor is now connected to the bracket.
