Signode SCM-12 - Troubleshooting Common Issues

13
TROUBLESHOOTING
The following items are the most common tool symptoms if problems should occur. For
symptoms or remedies not shown, contact your Signode service representative for additional
information and details. The following tool symptoms are shown in this manual:
#1 SYMPTOM: Difficult strap slack removal.
#2 SYMPTOM: Poor tensioning
#3 SYMPTOM: Joint fails after tool is removed or joint not made properly.
#4 SYMPTOM: Excessive effort needed to seal straps together.
#5 SYMPTOM: Tool will cut-off strap after sealing , or bottom strap cut too deep.
#6 SYMPTOM: Tool cannot be removed from strap after cycle is completed.
#7 SYMPTOM: Feedwheel slips during tensioning.
#1 SYMPTOM: Difficult strap slack removal.
CAUSE
REMEDY
1.
Strap not lubricated or not waxed
adequately.
2.
Strap not inserted properly (strap
caught by outer guide)
3.
Damaged parts in tension sub-
assembly.
1.
Purchase only lubicated (waxed)
strapping.
2.
Insert and align straps in tool properly.
3.
Inspect the tension assembly’s ratchet
wheel and pawls for damage or broken
parts.
#2 SYMPTOM: Poor tensioning.
CAUSE
REMEDY
1.
Feedwheel or clutch plug packed with
dirt or grit.
2.
Feedwheel or clutch plug teeth are
worn.
3.
Strap not properly aligned when
inserted into tool.
1.
If top strap is slipping, clean dirt from
the feedwheel or replace worn
feedwheel if necessary.
2.
If bottom strap is slipping, clean dirt
from the clutch plug or replace worn
clutch plug if necessary.
3.
Insert strap into tool carefully aligning
strap.
NOTE: Carefully inspect strap applied to determine if top or bottom strap is slipping.
