Signode SCM-12 - Table of Contents; Introduction

4
Signode
tools
and
machines
are
designed
and
warranted
to
work
toget
h
er
with
Signode strapping and seals. Use of non-
Signode
strap,
seals
and/or
manufactured
or
specified
repla
c
ement
parts
may
result
in
strap
breakage
or
joint
separation
while
applying
strapping
to
a
load
or
during
normal shipping
and handling. This could
result in severe personal injury.
TABLE OF CONTENTS
Page
General Safety Instructions
2
Introduction
4
Specifications
5
Major Components
5
Operating Instructions
6
Strap Joint Formation & Appearance
8
Adjustments
9
Parts List
10
Troubleshooting
13
Changing Strap Sizes
16
Tool Options
18
Declaration Of Conformity
19
INTRODUCTION
The SCM is a light weight, manually operated hand tool intended for use with Apex and Magnus
strapping. The tool is easy to load, tension and seal.
Once the strap has been placed around the package, the operator puts both layers of strap into
the tool, lowers the feed wheel, removes any strap slack and tensions the strap. The keyed
sealless joint is then created and the strap is cut free of the supply.
This manual provides the information necessary for the operation of the SCM hand tool and lists
all of the parts in the event maintenance is needed. Therefore, it is valuable and should be saved.
Extra care should be taken in performing maintenance on the SCM since fasteners and other small
components used on this tool are a combination of SAE and metric sizes.
