SIIG USB 3.0 - Package Contents; Layout; Hardware Installation

2
Package Contents
• USB 3.0 Switch 2-to-1
• 2x USB 3.0 cables
• Quick installation guide
Layout
Figure 1: Layout
Hardware Installation
1. Connect the included cable's Type B
connector into the switch, then connect the
Type A connector into your system's USB
port. Apply the same procedures with the
other cable.
To PC (Type B connector)
Power LED/Manual
switching button
To USB device
(Type A connector)
