UM-FULL-30SL rev A 2
REMOTE CONTROL TRANSMITTERS
CHANGING THE BATTERY IN YOUR TRANSMITTERS
SLRF434: The transmitter uses one (1) 3-volt lithium ion battery (#CR2032) with the (+) side facing upward.
To replace the battery, you will need to use a small at blade screwdriver. Locate the small notch on the lower
right side of the transmitter case next to the key ring. Using the at blade screwdriver, carefully pry the top
case from the bottom case. It should snap apart after breaking the seal. Before removing the battery note the
direction of the positive (+) terminal. Place the new battery in exactly the same manner, being careful not to
bend or damage the contact terminal. Snap the cases back together and then test the transmitter to insure it
arms and disarms the alarm.
OPERATION
TRANSMITTER OPERATION
Transmitter Button System Function Remark
Button
Lock Door / ARM ARM (OPTIONAL)
– Button
Arm and Delete
Optional Sensor
Press Twice (OPTIONAL)
Button
Car Locator While System Armed
Button for 3 Seconds
Panic Function Press 3 Seconds
Button
Unlock Door / DISARM
– Button
Two Steps Door Unlock &
Disarm System
Press Twice within 3 Seconds.
(Optional Installation and
Programming Required)
Button for 3 Seconds
Pop Trunk Release Press 3 Seconds
+ Button
Silent LOCK / UNLOCK Ignition in “OFF” Position.
+ Button for 1 Seconds
Activate Car-Jacking
(OPTIONAL)
Ignition in “ON” Position.
SILENT LOCK / UNLOCK or CH4 Must be Programmed to Use as CH4.
+
Switching Code for
2nd Car Operation.
Press and hold until TX LED is “ON”
SLRF434 Transmitter Battery Replacement
CR2032
+Side DOWN
