Air outlet flap valve
• Figure A: irrespective of which mode
the device is being operated in, open
the top flap valve 1. It's infinitely adjust-
able. If the flap valve is not opened, the
overheating protection will switch the
device off after a while for approx.
3minutes.
7.2 Displays
The mode of operation LEDs 16 and the dis-
play 15 show the selected functions and the
humidity range.
Mode of operation LEDs
Display
LED illuminated
Meaning
TANK FULL
The water tank is
full or has not been
inserted.
TIMER
A switch-off time is
activated.
AIR CLEAN
DRY CLOTHES
TARGET-HUMIDITY
AUTOMATIC
Selected mode
OPERATION
The device is
switched on.
Display
Meaning
This display can be seen
continuously during oper-
ation. It shows the humid-
ity range in the room:
LOW:
under 65%
MID:
65% to 75%
HIGH:
over 75%
NOTE: this display is not
visible if the child safety
lock is activated.
LC
The child safety lock is
activated. The device
cannot be operated by
using the buttons.
1 - 24
flash for 5 sec.
Timer for all modes:
These values (1 - 24 hours)
will flash for 5 seconds
when you use the arrow
keys to select a switch-off
time.
30 - 80 or CO
flash for 5 sec.
Enter relative humidity as
target humidity.
Values between 30 and
80 or CO will flash for
5seconds when
selected.
CO: The device dehu-
midifies continuously.
