Silvercrest SV 120 A1 - Description of the Appliance; Technical Data

■ 58
│
GB
│
MT
SV 120 A1
Description of the appliance
Figure A
1 Appliance lid
2 Suction tube
3 Cable retainer
4 Welding wires
5 Lower sealing ring
6 Rear limiters
7 Front limiters
8 Lid release
9 Suction fitting
0 Upper sealing ring
q Press seal
Figure B
w Red control lamp (for monitoring sealing process)
e
button (external vacuuming/stop process)
r
button (seal/stop process)
t
button (vacuum/stop process)
z Green control lamp (for monitoring vacuuming process)
Figure C:
u Vacuum hose for bag
i Suction cup
o Adapter for connecting to appliance
p Vacuum hose for container
a Adapter for containers
s Adapter for connecting to appliance
d Adapter for containers with a large valve diameter
Technical data
Operating voltage
100 - 240 V ∼ (alternating current),
50/60 Hz
Power consumption 120 W
Protection class
II /
(double insulation)
