SIM800_Hardware Design_V1.09 12 2016-06-30
Table 2: Coding schemes and maximum net data rates over air interface
Coding scheme
1 timeslot
2 timeslot
4 timeslot
CS-1
9.05kbps
18.1kbps
36.2kbps
CS-2
13.4kbps
26.8kbps
53.6kbps
CS-3
15.6kbps
31.2kbps
62.4kbps
CS-4
21.4kbps
42.8kbps
85.6kbps
2.2. Operating Modes
The table below summarizes the various operating modes of SIM800.
Table 3: Overview of operating modes
Mode
Function
Normal
operation
GSM/GPRS
SLEEP
Module will automatically go into sleep mode if the conditions of sleep
mode are enabling and there is no on air or hardware interrupt (such as
GPIO interrupt or data on serial port).
In this case, the current consumption of module will reduce to the
minimal level.
In sleep mode, the module can still receive paging message and SMS.
GSM
IDLE
Software is active. Module registered to the GSM network, and the
module is ready to communicate.
GSM
TALK
Connection between two subscribers is in progress. In this case, the power
consumption depends on network settings such as DTX off/on,
FR/EFR/HR, hopping sequences, antenna.
GPRS
STANDBY
Module is ready for GPRS data transfer, but no data is currently sent or
received. In this case, power consumption depends on network settings
and GPRS configuration.
GPRS
DATA
There is GPRS data transfer (PPP or TCP or UDP) in progress. In this
case, power consumption is related with network settings (e.g. power
control level); uplink/downlink data rates and GPRS configuration (e.g.
used multi-slot settings).
Power off
Normal Power off by sending the AT command “AT+CPOWD=1” or using the PWRKEY.
The power management unit shuts down the power supply for the baseband part of the
module, and only the power supply for the RTC is remained. Software is not active. The
serial port is not accessible. Power supply (connected to VBAT) remains applied.
Minimum
functionality
mode
AT command “AT+CFUN” can be used to set the module to a minimum functionality
mode without removing the power supply. In this mode, the RF part of the module will not
work or the SIM card will not be accessible, or both RF part and SIM card will be closed,
and the serial port is still accessible. The power consumption in this mode is lower than
normal mode.

SIM Tech SIMCom SIM800 Specifications

General

Frequency Bands	Quad-band 850/900/1800/1900MHz
Compliant to GSM Phase	2/2+
Low Power Consumption (Sleep Mode)	1.0mA
Operating Temperature	-40°C to +85°C
Data Rate	GPRS: Max. 85.6 kbps (downlink), Max. 42.8 kbps (uplink)
GPRS Multi-slot Class	Class 10
GPRS Mobile Station	GPRS mobile station class B
Transmitting Power	Class 4 (2W) @ 850/900MHz, Class 1 (1W) @ 1800/1900MHz
GPRS Data Features	PBCCH support, Coding schemes CS 1, 2, 3, 4
SMS	Text and PDU mode, MO / MT
USSD	Support
Supply Voltage	3.4V - 4.4V
Dimensions	24mm x 24mm x 3mm
Certifications	CE, RoHS
