Page 15
Technical Specifications
Audio
Inputs, (4 stereo)
Input impedance, 47 Kohms
Typical input level, 300 mv
Frequency response 20 to 20KHz, +/- 3db (bypass mode)
Signal to Noise ratio, greater than 70 db
THD less than 0.1% (bypass mode)
Left to right separation, greater than 60 db
Channel to channel separation, greater than 60 db
Outputs, (2)
Output Impedance, less than 150 ohms
Video
Input (4)
Composite Video (RCA style phono jack)
75 ohm, unbalanced, 1 v p-p
S-Video (4 pin mini DIN)
Y: 1 vp-p, 75 ohms, unbalanced
C: 0.286 V p-p, burst signal, 75 ohms
Outputs, (2)
Composite Video (RCA style phono jack)
75 ohm, unbalanced, 1 v p-p
S-Video (4 pin mini DIN)
Y: 1 vp-p, 75 ohms, unbalanced
C: 0.286 V p-p, burst signal, 75 ohms
Power Input: 15 VDC, 500 ma
Size: 13” wide, 8” deep, 2.25” high
Weight: 3 lbs, 10 oz.
Supplied accessories
AC adapter, 15 VDC, 500 ma output
SRC- IR remote control
A/V cable, 3’
User Manual (this document)
Design and specifications are subject to change without notice
