1.3 TECHNICAL FEATURES
19 26 37 48 55
Heat output kW 22,0 30,5 39,1 48,8 60,7
kcal/h 18.900 26.200 33.600 42.000 52.200
Heat input kW 25,0 34,8 44,8 55,0 69,2
kcal/h 21.500 29.900 38.500 47.300 59.500
Number of sections 34567
Water content l1013161922
Power consumption W
5-16*-100** 5-16*-100** 5-16* 5-16* 5-16*
Maximum water head bar44444
Maximum temperature °C 95 95 95 95 95
Loss of head
Water (∆t 30°C) mbar 2,0 3,0 4,5 5,5 10,3
Expansion vessel
Water content l 8 10 – – –
Preloading pressure bar 1 1 – – –
Smokes temperature ° C 119 118 110 13 0 141
Smokes flow gr/s 24,7 34,7 52,2 53,1 59,2
Category II
2H3+ II2H3+
II2H3+ II
2H3+ II2H3+
Type B11BS
B11BS
B11BS B11BS B11BS
Weight kg 101-113** 126-138** 150 176 202
Main burner nozzles
Quantity n° 22333
Methane ø mm 3,15 3,65 3,40 3,90 4,05
G30 - G31 ø mm 1,80 2,10 1,95 2,20 2,45
Pilot nozzles
Methane ø mm 0,29 0,29 0,29 0,29 0,29
G30 - G31 ø mm 0,24 0,24 0,24 0,24 0,24
Gas consumption ***
Methane m
3
s/h 2,64 3,68 4,73 5,82 7,32
Butane (G30) kg/h 1,97 2,74 3,53 4,34 5,45
Propane (G31) kg/h 1,94 2,69 3,47 4,27 5,37
Burner gas pressure
Methane mbar 9,8 9,6 9,6 9,1 11,5
Butane (G30) mbar 28 28 28 28 28
Propane (G31) mbar 35 35 35 35 35
Gas supply pressure
Methane mbar 20 20 20 20 20
Butane (G30) mbar 30 30 30 30 30
Propane (G31) mbar 37 37 37 37 37
* “IONO” vers. ** “PVA” vers. *** The gas consumptions refer to the calorific value at standard conditions at 15°C - 1013 mbar
