User’s Manual
DRUM Amplifier
1
2
3
4
1
4
2
3
back panel
6
Extension Speakers Jacks: The DA200S
delivers the full 200 watts of power to the internal
speakers. In addition, you may use these jacks with
un-powered speakers to widen your stereo field for
the midrange and high frequencies.
Left and Right Line Outs: These balanced
XLR Line Outs provide quiet, noise-free signal flow
through a standard mic cable or snake to a recording
or live console.
Volume Control for Line Outs: This control
is completely independent from the Master volume on
the front panel, allowing you to set your feed level to
a mixing console. Use the Master volume on the front
panel to adjust your stage level.
Ground Lift: Use this switch to eliminate hum or
buzz that may exist if there is a ground loop created
between stage gear and the PA system.
