Simmons DA200S - Technical Specifications; DA200 S Specifications Details

DA200S
www.simmonsdrums.net
specifications
Model DA200S Electronic Drum Amp
Output Power (RMS 1% ) 50 Watts @ 8 Ohms (x2) Tweeter Internal Speakers (Stereo)
50 Watts @ 4 Ohms (x2) Midrange Internal Speakers (Stereo)
100 Watts @ 8 Ohms (x1) Subwoofer Internal Speaker (Mono)
500 mWatts @ 32 Ohms (x2) Output to Headphones (Stereo)
Frequency Response 20 Hz - 20 kHz Tailored for accurate acoustic response
for electronic drums
Hum and Noise -60dBV Allcontrolsturneddown 
 -55dBV Allcontrolsturnedhalfway
Input Impedance 10K Ohms All Inputs
Input Levels -16dBV DrumInputstoachievefulloutput   
 -20dBV Auxtoachievefulloutput
 -10dBV LineIntoachievefulloutput
External Outputs Max External Speaker Output: 30 Watts (x2) Extension Speaker Jacks are wired in series
with internal midrange speakers.
 XLRBalancedLineOutputs Adjustablefromo(CCW)to0dBV(CW).
Wiring follows IEC268 standard (pin1 shield,
2 +, and 3 –).
Tone controls (EQ Centers) 50Hz,800Hz,10kHz 3band,+/–12dB
AC Power Requirements 400 Watts At full output
14 Watts At idle
Speakers 12” (305 mm) Woofer Special design, 8 Ohms rated 150 Watts RMS
2 x 6.5” (165 mm) Midrange Special design, 4 Ohms rated 65 Watts RMS
2 x 2.5“ (64 mm) Tweeter Special design, 8 Ohms bullet horn rated 50 Watts RMS
Dimensions (English) 161/2”Deep,173/4”Wide,20”Tall
(including feet)
Dimensions (Metric) 420 cm Deep, 450 cm Wide, 508 cm Tall
(including feet)
Weight 57lbs./25.8Kg.   
(All measurements made at 1 kHz,
EQ controls flat and volumes Max.)
7
