Advanced Operations
Effects Settings
The SD1000 sound module has built-in Reverb and 4 Band EQ effects, which are adjustable
in the Utility Effects setup. The available parameters are available below.
Item Explain Pararameters Default
Reverb
Master reverb switch OFF/ON
RvbTyp
Reverb type
SRoom/MRoom/LRoom/Hall1/Hall2/
Plate/Delay/P.Dely
EQSwitch
4 band EQ master switch OFF/ON
According to
current KIT
EQLow
EQ low band -12DB
~
12db
EQL.Mid
EQ low middle band -12DB
~
12db
EQH.Mid
EQ high middle band -12DB
~
12db
EQHigh
EQ high band -12DB
~
12db
To change the assignment for the Reverb:
1. Press the [UTILITY] Button.
2. Press the [PAGE -/+] buttons to select EFFECT.
3. Press [SAVE/ENTER]. You will see the Reverb screen.
4. Press the [PAGE +] button.
5. Press the [-/+] buttons or VALUE DIAL to select the Reverb type.
To change the settings for the Master 4 Band EQ:
1. From the Reverb type screen press the [PAGE +] button. You come to the EQ Switch screen.
2. Press the [PAGE -/+] buttons to select the EQ parameters that you want to change.
NOTE: If you want to save all the effects for the current kit, see the “Saving a Kit” section.
