Assembling your Kit
Attaching the Cymbal Pads
1. Insert each cymbal arm into the rack clamp.
2. Insert short hi-hat arm on the left-side arm’s cymbal clamp.
3. Remove wing nut from cymbal tilter. Place cymbal pad on tilter assembly.
4. Re-attach washer and wing nut. Tighten wing nut.
Attaching the drum module
1. Loosen wing screw on drum rack.
2. Place drum module into drum clamp.
3. Tighten wing screw to secure module
