3200 PSI Gas Pressure Washer
039-8056-0
Congratulations on the purchase of your new pressure washer. In order
to ensure you have the best possible experience please read through the
following instructions. If you require any help, please contact the customer
service department at:
1-866-4SIMONIZ
(1-866-474-6664)
Contact us for assistance; we’re here to help.
Model no. XG01
Version no. 02
Use and Care Guide
XG01_3200PSI_E.indd 1 2016-12-05 4:11 PM

Table of Contents

Questions and Answers

  • D
    dustinestradaAug 16, 2025
    Why is there no pressure or low pressure in my Simoniz 039-8056-0 Pressure Washer?
    • J
      Julie HamiltonAug 16, 2025
      There are several reasons why your Simoniz Pressure Washer might have low or no pressure: * The nozzle tip might not be attached, so attach the required nozzle tip. * The water supply faucet might be closed; turn it on and ensure there are no kinks or blockages in the hose. * The water supply pressure might be low; ensure the faucet is fully opened and that the water supply is a minimum of 30 PSI, 4 GPM. * There might be air in the pump; squeeze the trigger to release the air while the machine is running. * The loaded RPM might not be set to FAST; set the RPM (Throttle lever) to the FAST position.
  • E
    edwardmonroeAug 19, 2025
    What to do if my Simoniz 039-8056-0 Pressure Washer engine doesn’t start or is difficult to start?
    • L
      Luis MoranAug 19, 2025
      If your Simoniz Pressure Washer engine is not starting or is difficult to start, consider the following: * Ensure the engine power switch is in the ON (I) position. * Fill the fuel tank with regular gasoline if it's empty. * Add oil until it reaches the minimum level on the dip stick if the low oil shut down sensor tripped. * Release water pressure by squeezing the trigger on the gun if there is excess water pressure in the pump or hose. * When cold starting the engine, set the choke to CLOSE or OFF. When warm starting, set the choke to OPEN or ON or try the middle position if the choke lever is not in the right position.
  • K
    Kristina JenningsAug 22, 2025
    How to fix a Simoniz 039-8056-0 when there is no intake of detergent?
    • I
      ivan21Aug 22, 2025
      If your Simoniz Pressure Washer isn't taking in detergent, here's what to check: * Ensure the detergent siphon tube is properly connected. * Replace the detergent siphon tube if it's damaged. * Use the black nozzle when applying detergent. * Clean the nozzle if it's clogged. * Detach the detergent siphon tube and clean the fitting with a tip cleaner if the pump detergent siphon fitting is clogged. * Use only detergent approved for use with pressure washers, as thick detergent or a clogged detergent filter can cause issues.
  • W
    Willie BeckAug 25, 2025
    What causes a Simoniz Pressure Washer engine to lack power?
    • J
      Jim FloydAug 26, 2025
      A Simoniz Pressure Washer engine may lack power if the air filter is clogged, so clean or replace it. It can also be caused by a clogged carburetor.
  • J
    Jennifer ZunigaAug 28, 2025
    How to fix a Simoniz Pressure Washer when detergent is not working?
    • A
      Andre GomezAug 28, 2025
      If the detergent is not working with your Simoniz Pressure Washer, consider the following: * Add more detergent if the detergent container is empty. * Check connections if the detergent bottle or suction tube are not properly connected. * Dilute the detergent if it is too thick. * Remove any obstruction or replace the detergent suction tube if it is damaged or clogged. * Blow out or remove debris with a fine needle if the discharge nozzle is obstructed. * Set the detergent ON/OFF knob to the ON position if it is at the OFF position.
  • A
    andrea97Aug 31, 2025
    Why does my Simoniz 039-8056-0 engine stop after starting?
    • R
      Robert TorresAug 31, 2025
      Your Simoniz Pressure Washer engine might stop shortly after starting due to: low oil or no fuel, so check the oil and fuel levels. Alternatively, the choke lever may be in the Close position; if so, move it to the Open position immediately after starting the engine.
  • C
    Cindy MackSep 3, 2025
    What to do if my Simoniz 039-8056-0 trigger can’t be squeezed?
    • A
      Alan KellySep 3, 2025
      If the trigger on your Simoniz Pressure Washer can’t be squeezed, it may be because the safety lock is not open. Open the safety lock.
  • L
    Lisa RojasSep 6, 2025
    What causes a Simoniz 039-8056-0 carburetor to leak?
    • M
      matthewsjaniceSep 6, 2025
      A carburetor leak in your Simoniz Pressure Washer is usually caused by a clogged carburetor. Clean the carburetor.
  • T
    tuckerkellySep 9, 2025
    Why does my Simoniz Pressure Washer engine stop when moving or tilted?
    • S
      Shelby YoungSep 9, 2025
      The Simoniz Pressure Washer engine might stop while moving or being tilted because the low oil shut down sensor tripped to protect the engine. Do not tilt the machine past 15° when operating. Check the oil level and ensure it is above the minimum level on the dip stick.
  • B
    brittany69Sep 12, 2025
    Why is the pressure too high on my Simoniz 039-8056-0 Pressure Washer?
    • S
      simmonssheilaSep 12, 2025
      If the pressure is too high on your Simoniz Pressure Washer, it is likely due to a clogged nozzle. Clean the nozzle with a tip cleaner.

Summary

Safety Advice

Definitions

Explains safety symbols like Danger, Warning, Caution, and hazard types.

Safety Warnings

Provides general safety guidelines and conditions to avoid during operation.

Safety Advice (cont.)

Safety Warnings (cont.)

Covers work area safety, ventilation, engine heat, and personal safety precautions.

Safety Warnings (cont.)

Addresses flammable materials, engine safety, and potential chemical hazards.

Safety Warnings (cont.)

Details specific safety advice, injection hazards, detergent use, spray gun, and water connections.

Safety Warnings (cont.)

Covers service safety, cold weather operation, safety features, and pump damage prevention.

Intended Application

Exploded View

Assembly Instructions

Surface Preparation

Ensures the work area is safe and free from hazards before starting.

Water Supply (Cold Water Only)

Specifies requirements for the cold water supply and hose.

Assembly Steps

Provides initial steps for assembling the pressure washer unit.

Assembly Instructions (cont.)

Assembly Steps (cont.)

Continues assembly instructions with attachment steps and hose connections.

Assembly Steps (cont.)

Details spray tip selection and adjusting pressure settings for various tasks.

Engine Operation

Adding;Checking Oil

Guides on checking and adding engine oil, emphasizing importance before use.

Engine Operation (CONT.)

Adding Fuel

Instructions on safely adding clean, fresh, unleaded gasoline to the fuel tank.

Engine Operation (cont.)

Checking Air Filter

Procedure for inspecting and cleaning the engine's air filter element.

Purging

Steps to remove air from the pressure washer system before operation.

Starting Engine

Step-by-step guide for starting the pressure washer engine correctly.

Stopping Engine

Step-by-step guide for safely shutting down the pressure washer engine.

Cleaning with Detergent Instructions

Cleaning with Detergents

Explains how detergents enhance cleaning and provides usage advice.

Working with the Detergent Injection Tube

Instructions for using the detergent injection system with the spray gun.

Cleaning with Detergent Instructions (cont.)

Working with the Detergent Injection Tube (cont.)

Details on rinsing the detergent injection tube after use.

Working with the Foam Blaster

Guide on assembling and preparing the foam blaster for use.

Working with the Foam Blaster (cont.)

Instructions for operating foam blaster settings and cleaning it.

Operation Instructions

Using Pressure Washer

Basic steps for operating the pressure washer, from starting to positioning.

Shutting Down and Cleaning Up

Procedures for safely stopping, cleaning, and depressurizing the unit.

Using Spray Nozzle

Details on the different spray nozzles, their uses, and installation.

Cleaning and Maintenance

Cleaning the Spray Tips

Instructions for cleaning spray tips to maintain water pressure and pump health.

Cleaning Water Inlet Filter

Importance of the inlet filter and procedure for cleaning it.

Engine Maintenance

Covers engine oil changes, spark plug checks, and related maintenance.

Cleaning and Maintenance (cont.)

Engine Maintenance (cont.)

Details spark plug removal, checking gap, and installation procedures.

Short Term Storing

Guidance for safely storing the pressure washer for short periods.

Long Term Storing

Steps for preparing the unit for extended storage, including fuel treatment.

Long Term Storing (cont.)

Procedure for draining oil and winterizing the pressure washer for protection.

Winterizing Procedures

Steps to protect the unit from freezing and rust during winter storage.

Technical Specifications

Troubleshooting

Troubleshooting Engine

Guides for diagnosing and resolving common engine starting and running issues.

Troubleshooting (cont.)

Troubleshooting Pump

Guides for diagnosing and resolving common pressure washer pump problems.

Troubleshooting Accessories & Connections

Guides for common issues with spray gun, hoses, and detergent systems.

Troubleshooting Accessories & Connections (cont.)

Addresses further issues with detergent systems and hose connections.

Limited Warranty

Simoniz 039-8056-0 Specifications

General IconGeneral
BrandSimoniz
Model039-8056-0
CategoryPressure Washer
LanguageEnglish
