Important: Notify the appropriate personnel (building occupants, fire
department, monitoring facility, etc.) of the installation.
The following paragraphs contain material which is applicable to all 4009
NAC Power Extender systems. Be sure that you are thoroughly familiar with
this material before installing your 4009.
To help you with installation of this and other Simplex equipment, the following
publication is available for general reference: How to Wire a Building for a
Fire Alarm System.
The following tools and equipment are required to install the 4009:
• 1/4-inch flat-tip screwdriver, 8-inches long
• 1/8-inch flat-tip screwdriver, 4-inches long
• Volt-Ohmmeter
• Diagonal cutting pliers
• Wire strippers
• End-of-line resistors (supplied by Simplex)
• Field Wiring Diagram 841-925.
1. All wiring must be done in accordance with local codes.
2. A minimum of 6 inches of free conductor is required is each electrical box
to facilitate termination’s.
3. A 12-inch service loop of cable is required for all continuous pulls through
an electrical box.
4. All system wiring subject to physical damage must be mechanically
protected based on the environment to which the cable is subjected.
5. A neatly wired system helps assure an accurate inspection of all connections
and simplify troubleshooting.
Continued on next page
System Installation
General Information
Tools and Equipment
Required
General Notes
