Single Block Option Modules, Select Three (3) Maximum i
No Dual Block Module is Selected;
Select One (1) Maximum if a Dual Block Module or the Module Bracket is Selected
Model Features Option Block Usage
Supervisory
Current
Alarm
Current
4010-9912
Serial DACT, includes 2, 2080-9047 cables, 14 ft
(4.3 m) long, RJ45 plug and spade lugs
1 Block
(must mount in block D
under ESS)
30 mA 40 mA
4010-9908 4 Point Aux Relay Module 1 Block 15 mA 60 mA
4010-9916
Voltage Regulator Module, 22.8 to 26.4 VDC
(25 VDC nominal); isolated and resettable output;
includes earth detection circuit and trouble relay for
status monitoring
1 Block
3 A maximum
with 2.5 A load
4.9 A
maximum
with 4 A load
4010-9918 Dual RS-232 Module 1 Block 60 mA 60 mA
4010-9930
Dual Class A IDNAC Isolator (DCAI); converts a
single Class B IDNAC SLC input to two Class A or
two Class B SLC outputs; provides short circuit
isolation between each Class A or B output circuit;
requires one IDNAC address; the total current
remains controlled by the Class B input source SLC
at 3 A maximum; select up to 2 per IDNAC SLC
1 Block
Note: One DCAI module can
be mounted on the ESS
8.3 mA 18.5 mA
4010-9915
BACpac Ethernet Portal Module; requires
4010-9918 RS-232 Module (no address required)
1 Block 123 mA 123 mA
4010-9901 VESDA HLI 1 Block 60 mA 60 mA
Dual Vertical Block (Flat) Modules, Select One, or Two with 4010-9928 Bracket Kit (except for Media Cards)
Model Features Option Block Usage
Supervisory
Current
Alarm
Current
4010-9928
Dual Vertical Block Card Mounting Kit, allows
selecting two, dual Vertical Block (flat) modules
from the list below
2 Vertical Blocks NA NA
4010-9922
Modular Network Interface Card
(requires two media modules, see below)
2 Vertical Blocks 30 mA 30 mA
4010-9818 Network Media Card Wired
N/A
(mounts to 4010-9922)
55 mA 55 mA
4010-9819 Network Media Card Fiber Optic 25 mA 25 mA
4010-9914 Building Network Interface Card 2 Vertical Blocks 236 mA 236 mA
4010-9923* SafeLINC Internet Interface 2 Vertical Blocks 115 mA 115 mA
4010-9924* Modem Physical Bridge Class B
Requires one of the 2
Vertical Block spaces on the
4010-9928 Mounting Kit
193 mA 193 mA
4010-9925* Modem Physical Bridge Class X 246 mA 246 mA
4010-9926** TCP/IP Physical Bridge Class B
3 Block “L” Shape, requires
one of the 2 Vertical Block
spaces on the 4010-9928
Mounting Kit, plus Block D
196 mA 196 mA
4010-9927** TCP/IP Physical Bridge Class X 236 mA 236 mA
Dual Vertical Block (Slot) Modules, Select One if no Dual Vertical (Flat) Modules from Above are Selected
Model Features Option Block Usage
Supervisory
Current
Alarm
Current
4010-9920 8 Zone Initiating Device Circuit - Class B
2 Vertical Blocks
(mother/daughter card)
75 mA 195 mA
4010-9921 8 Zone Initiating Device Circuit - Class A
*UL, ULC, and CSFM listed.
** FM Approved only.
Addressable Channel Loading Reference Device Load
Supervisory
Current
Alarm Current
IDNet 2 Communications Channel Output for every 50 Devices 40 mA
1 mA per device in alarm; 2 mA
per activated device LED
IDNAC Communications Channel Output for every 50 Appliances 40 mA calculate per selected appliances
7 S4010-0011-5 11/2015
Addressable Device Load Specifications for Battery Standby
Block Space Option Card Selection
Note: Refer to diagram on page 2 for Option Module availability. Supervisory and Alarm current specifications are for determining
battery standby requirements.
