Simplex 4010ES Quick Reference Guide

P2 P3 P4
P19
P18
A B C D E Descrip�on
LED15 LED14 LED13 LED12 LED11
Debug LED
OFF OFF OFF OFF OFF No Trouble: There are no troubles detected on the ESS.
ON OFF OFF OFF OFF AC Fail: The AC power is disconnected, but the baery is working.
OFF ON OFF OFF OFF Low Baery: The baery is under 22V.
ON
ON OFF OFF OFF
Baery Cutout: The Baery charge is below 20V. At this point, if Jumper P19
is set to “baery disconnect when depleted” the system shuts down.
OFF OFF ON OFF OFF
Depleted/Missing Baery: If jumper P19
is not set to “baery disconnect
when depleted”, this trouble appears when the baery charge is below
20V. This code also appears if the system cannot detect the baery.
ON OFF ON OFF OFF Charger Trouble: There is a trouble with the baery charger.
OFF ON ON OFF OFF Card Overcurrent: The module is drawing too much current.
ON ON ON OFF OFF Negave Earth: The circuit is shorted to ground on the negave wire.
OFF OF
F OFF ON OFF Posive Earth: The circuit is shorted to ground on the posive wire.
ON OFF OFF ON OFF
City Circuit 1 Trouble: The trouble congured on the City Card’s
Circuit 1 has been triggered.
OFF ON OFF ON OFF
City Circuit 2 Trouble: The trouble congured on the City Card’s
Circuit 2 has been triggered.
ON ON OFF ON OFF
AuxNAC Open: Depending on the chosen conguraon,
either the Aux circuit or the NAC Circuit is open
.
OFF OF
F ON ON OFF
AuxNAC Short: Depending on the chosen conguraon,
either the Aux circuit or the NAC Circuit is experiencing a short circuit.
ON OFF ON ON OFF
AuxNAC Overcurrent: Depending on the chosen conguraon,
either the Aux circuit or the NAC circuit is drawing too much current.
LED 9
AC
LED 10 Comm Loss
LED 11 E ESS debug LED
LED 12 D ESS debug LED
LED 13 C ESS debug LED
LED 14 B ESS debug LED
LED 15 A ESS debug LED
LED Name
LED 1 IDNet Negave Earth Fault
LED 2 IDNet Posive Earth Fault
LED 3 IDNet Trouble
LED 4 IDNet Com
LED 5 IDNet Loop A Trouble
LED 6 IDNet Loop B Trouble
LED 7 IDNAC 1 Trouble
LED 8 IDNAC 2 Trouble
SIMPLEX 4010ES with ESS Main Board
LEDs 1-6
TB1 TB2 P11
P7
P9
P13
LEDs 7-15TB4
SW1
TB3
P2
P3 and P4
P7
P9
P11
P13
P18
P19
SW1
IDNet 4100 Comms Enable
Jumpers select IDNet Class A/B
City/Relay Card, A 10-posion connector is provided for the ribbon harness that goes to a City Card or Relay Card
Posive baery connecon
Connecon plug for an oponal Dual Class A Isolator (DCAI) card
Negave baery connecon
Disables 4100 Communicaons between the power supply and IDNAC funcons


Descrip�on
P Connectors
and Switch
TB1 IDNet Connec�ons
TB2 IDNAC Connec�ons
TB3 Aux/Simple NAC
TB4 Relay
Provides 2 fault isolated loops of IDNet +.
TB1 (1-4) Loop A, TB1 (5-8) Loop B
Each IDNAC circuit has a 4 posion terminal block.
TB2 (1-4) IDNAC 1,TB2 (5-8) IDNAC 2
Provides 2 posions for wiring the aux power
and reverse polarity supervision circuit.
A 32V, 2A relay is provided with both
NO and NC contacts.
Descrip�on
Terminal Block
2
