When finished with scanning and storing, or if the limit of the memory is
reached, the data in the non-volatile memory can be downloaded through the
serial port located on the right side of the data reader. A serial cable must
connect the reader to a computer with upload capabilities. The data is
transferred by depressing the D/L button. If the reader is holding a valid
reading, and the green LED is lit, hold down the D/L button for approximately
two seconds. This is to protect against inadvertent clearing of the last reading if
it has not been stored.
To clear the non-volatile memory, power down the data reader then, while
pressing both the STORE and D/L buttons, power up the reader. Hold down
both buttons until the display indicates “#001” on the memory counter. This
procedure takes several seconds.
The display is a Liquid Crystal Display with two rows of 16 characters.
Examples of the display are shown below in Figure 1. When a valid reading is
made, the diagnostic data Hex code is first displayed. Next “XX%ALM” is
shown, where XX% is the percent to alarm of the last sample, then “#YYY”
where YYY is the next available non-volatile memory location. When the
battery runs low, a low battery message is displayed.
Figure 1. Examples of LCD Messages on the Reader
Refer to the 4098 Detectors, Sensors, and Bases Application Manual (574-709)
that was shipped with the fire alarm system for detector specification data and
maintenance. Refer to Table 2 for a listing of compatible detectors.
Table 2. Compatibility Table
Detector PID No. Description
4098-9601 Photoelectric Smoke Detector
4098-9602 Photoelectric Smoke/Heat Detector
4098-9605 Photoelectric Smoke Detector (3.5% ft. sensitivity)
Downloading (D/L) the Data
from Memory
Clearing the Memory
Display
Compatibility
SSD SERVICE TOOL
V1.02 #YYY
Power Up or
Scan mode
350E4C3D4OF8E1OE
1B XX%ALM #YYY
Diagnostic
Data
*** LOW BAT ***
V1.02 #YYY
Low Battery
Indication
