Figure 1 depicts the 100 W amplifier.
BAUD RATE/
ADDRESS DIP
OUTPUT
SWITCH (SW1)
TROUBLE LED
(LED2)
EXPANSION
NAC PORT 1
(P1)
NAC (SPEAKER CIRCUIT)
TERMINAL BLOCK (TB1)
EXPANSION
NAC PORT 2
(P3)
NAC TROUBL
E
LEDS (LEDs 5
through 10)
DIGITAL
AUDIO
DECODER
PORT (P2)
COMMS
TROUBLE LED
(LED1)
INPUT TROUBLE
LED (LED3)
AC POWER
LED (LED4)
BACKUP
AUDIO
TERMINAL
BLOCK (TB2)
Figure 1: The 100 W Amplifier
For LED descriptions, see the section on LED Indications.
page 3 579-174 Rev. Q
Digital/Analog Amplifiers Installation Instructions
