Simplex STS User Manual

8
connected or is obstructed the tank will distort
and possibly rupture. In installations where the
main fuel tank is above ground the overow pipe
should be connected to an Overow Tank (Option
#390 Recommended). DO NOT INSTALL A
VALVE IN THE OVERFLOW LINE!
3. Attach the Day Tank Intake Line (ll pipe) from
the main fuel tank to the pump inlet. is is an
NPT internal connection. Use black pipe with
a union and size per the dimensional drawing.
Optional fuel strainer (Option 060) with #60 mesh
is recommended.
4. Attach the Engine Supply Line. is is an NPT
external connection. Use black pipe with a union
and size per the dimensional drawing in this
manual. Attach the Engine Return Line. is is an
NPT internal connection. Use black pipe with a
union and size per the dimensional drawing.
5. Attach the Engine Return Line. is is a NPT
internal connection. Use black pipe with a union
and size per the dimensional drawing.
6. WARNING! Verify the Day Tank mode selector
switch is in the “O” position. Supply a 115-1-
60, 15A, circuit breaker protected circuit from
a reliable power bus to the control power ter-
minal board (TB”PS”) at terminals 1 and 2.
GROUND THE DAY TANK! Secure the conduit
end to the le side of the cover at the holes provid-
ed. Replace the cover.
Verify the Main Discon-
nect Switch and pump
Auto-Off-Run switches
are in the O󰀨 position
before performing instal-
lation procedure.
Risk of electric shock!
More than one Discon-
nect Switch may be re-
quired to de-energize
the equipment before
servicing.
IMPORTANT NOTE!! The system shall be for use with fuel oil as
described by NFPA321, “Basic Classication of Flammable and Com-
bustible Liquids.” As dened by this standard, the fuel supply system
shall be for use with “combustible liquids,” those having a ash point
at or above 100°F and further dened as Class II or Class III liquids. In
no case shall a liquids having a ash point less than 100°F be used. In
every case, the system shall not be used or applied at a temperture in
excess of the ash point of the contents. Electrical equipment used in
the system shall be in accordance with NFPA30, section 5-7, wherein
it states “For areas where Class II or Class III liquids only are stored
or handled at a temperature below their ash points, the electrical
equipment may be installed in accordance with provisions of NFPA70,
National Code, for ordinary locations...”
