Parts List
First things rst -- make sure have all of the necessary components in your
SimpliciKey package.
1 interior lock 1 interior plate
1 exterior lock
2 short bolts
2 long bolts
2 strike wood
screws
1 strike plate
1 reinforcement
plate
2 remote control
keyfobs
2 keys
1 deadbolt lock
1 strike box
2 short wood
screws
2 long
wood screws
32
LOCK INSTALLATION INSTRUCTIONS
1. Remove Existing Deadbolt
2. Check Cutout Size
Critical Point
First, remove the two interior screws
securing the lock.
Next, remove the interior and
exterior lock components.
Finally, take out the existing deadbolt
slide assembly.
Stop to measure the cutouts for the lock
components. If the main cutout is 2-1/8 inches in
diameter, and latch cutout is 1 inch, you’re ready
to go. If not, you may need to use the Advanced
Guide to help you adjust your door.
2 1/8”
1”
2” Thickness Max
