Features & Controls
CONTROLS - HYDRO MODEL
CONTROLS - GEAR MODEL
Figure 1. Tractor & Mower Controls - Hydro Model
Figure 2. Tractor & Mower Controls - Gear Model
A. Steering Wheel
B. Throttle
C. Parking Brake Knob
D. Ignition Key/Switch
E. Headlight Switch
F. PTO (Electric Clutch) Switch
G. Mower Height Adjustment Lever
H. Brake Pedal
I. Forward Direction Pedal
J. Rear Direction Pedal
A. Steering Wheel
B. Throttle
C. Parking Brake Knob
D. Ignition Key/Switch
E. Headlight Switch
F. PTO (Electric Clutch) Switch
G. Mower Height Adjustment Lever
H. Clutch/Brake Pedal
I. Gear Selector
A
H
I
G
F
E
D
A
H
G
E
I
F
C
B
D
C
J
B
