27
Specifications
ENGINE:
16 HP Kohler Command
Make Kohler
Model CommandTM CV16S
Horsepower 16 @ 3600 rpm
Cylinder 1
Bore 3.55 in (90 mm)
Stroke 2.64 in (67 mm)
Displacement 26.0 Cu. in (426 cc)
Construction Overhead Valve, Cast-Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 15 amp. Alternator Regulated
Battery: 12 Volt, 200 Cold Cranking
amps,
23 Min. Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam Pre-
Lubrication Full Pressure Lube w/Oil Filter
Oil Capacity 4.0 Pints w/Filter (1.9 L)
Fuel Tank Material: High-Density Polyethylene,
Transparent
Capacity: 2.0 Gallons (7.5 L)
Muffler Quiet Compact, Low Back Pressure
14 HP Kohler Command
Make Kohler
Model CommandTM CV14S
Horsepower 14 @ 3600 rpm
Cylinder 1
Bore 3.43 in (87 mm)
Stroke 2.64 in (67 mm)
Displacement 24.3 Cu. in (398 cc)
Construction Overhead Valve, Cast-Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 15 amp. Alternator Regulated
Battery: 12 Volt, 200 Cold Cranking
amps
23 Min. Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam Pre-
Lubrication Full Pressure Lube w/Oil Filter
Oil Capacity 4 Pints w/Filter (1.9 L)
Fuel Tank Material: High Density Polyethylene,
Transparent
Capacity: 2.0 Gallons (7.5 L)
Muffler Quiet Compact, Low Back Pressure
CHASSIS:
Frame Heavy Gauge Steel Channel - 12/14 Gauge
Engine Mounting: Above Front Axle
Pivot Point Location: Rear Carrier
Rear Wheels Tire Size: 20 x 8-8 Turf Type
Pneumatic Inflation Pressure: 12-15 psi (82-
103 kPa)
Front Wheels Tire Size: 15 x 6.00-6
Pneumatic Inflation Press.: 12-15 psi (82-103
kPa)
Bearings: Sintered Iron with Grease Fittings
Accessibility Hood Tips Forward, Seat Tips Forward for
Accessibility
Seat High-Back, Quick Adjust, Spring Suspension
Turning Radius Inside Rear Tire: 14 in (36 cm)
TRANSMISSION:
Hydro Models
Type Hydrostatic Tuff Torq K56
Pump Variable Displacement Axial Piston
Motor Fixed Displacement Axial Piston
Control Single Pedal Foot Control
Free-Wheeling Lever for Manual Tractor
Movement
Hydraulic Fluid 10w 30 Premium Engine Oil
Speeds Forward: 0-5.6 MPH (9.0 km/h)
@ 3400 rpm Reverse: 0-3.0 MPH (4.6 km/h)
Differential Bevel Gear Type
Axle Shaft .75 in
Continuous Torque 170 ft. lbs.
Output
Drawbar Rating 227 lbs.
Maximum Weight 673 lbs.
on Axle
Gear Models
Type Peerless MST 205, EP 90 Oil
Spur Gear
Material Shaft: Hardened
Bearings: Needle Roller & Bushings
Lubrication
Speeds Five Forward, One Reverse
Speeds 1st: 1.0 MPH (1.6 km/h)
@ 3400 rpm 2nd: 2.0 MPH (3.2 km/h)
3rd: 3.0 MPH (4.8 km/h)
4th: 4.2 MPH (6.7 km/h)
5th: 4.7 MPH (7.5 km/h)
Rev: 1.4 MPH (2.2 km/h)
Differential Bevel Gear Type
Axle Shaft .75 in
Continuous Torque 225 ft. lbs.
Output
Drawbar Rating 300 lbs.
Maximum Weight 525 lbs.
on Axle
CONTROLS:
Steering 13.5" (34 cm) Steering Wheel
Gear and Sector, 1.5 turns Lock to Lock
Clutch/ Combination Clutch/Brake/Parking Brake
Pedal
Brake Pedal Parking Brake Lock, Foot/Hand Activated
Location PTO Clutch Electric, Seat Deck
Hydro Models:Hydrostatic Control Single
Lever Foot Pedal,
Gear Models: Shift Lever: Seat Deck
R.H.
Ignition Key Switch: On Seat Deck
Throttle Lever & Choke Lever:
(Combined) On Dash Panel
NOTE: Specifications are correct at time of printing and are subject to change without notice.
