DO NOT TOW TRACTOR
Towing the unit will cause transmission
damage. • Do not use another vehicle to
push or pull this unit. • Do not actuate the
transmission release valve lever while the
engine is running.
Figure 5. Transmission Release Lever
A
Pushing the Tractor by Hand
1. Disengage the PTO and turn the engine off.
2. Pull the transmission release lever (A, Figure 5) back
approximately 2-1/2” (6 cm) to lock into released
position.
3. The tractor can now be pushed by hand.
If an operator chooses to mow in reverse, the RMO
system can be used. To use the Reverse Mowing Option
(RMO) turn the RMO key after the PTO is engaged. The
L.E.D. light will illuminate, and the operator can then
mow in reverse. Each time the PTO is disengaged the
RMO needs to be reactivated if desired. The key can be
removed to restrict access to the RMO feature.
Attachment Operation in Reverse
If an operator chooses to operate a PTO driven
attachment in reverse, the RMO system can be used. To
use the Reverse Mowing Option (RMO) turn the RMO key
after the PTO is engaged. The L.E.D. light will illuminate,
and the operator can then operate the attachment in
reverse. Each time the PTO is disengaged the RMO
needs to be reactivated if desired. The key can be
removed to restrict access to the RMO feature.
OPERATION
18
WARNING
Mowing in reverse can be hazardous to bystanders.
Tragic accidents can occur if the operator is not
alert to the presence of children. Never activate
RMO if children are present. Children are often
attracted to the unit and the mowing activity.
Mowing in Reverse
