Simplicity Colt ZT2148T User Manual

13
TP 400-7090-05-CT-D
The above parts group applies to the following Model Nos.:
ZT2148T (S/N 123 & below)
ZT2352T (S/N 123 & below)
REF NO. PART NO. QTY. DESCRIPTION
Fuel Supply Hose & Tank Replacement Part Group
Footnotes:
1 22030 1 VALVE, Fuel Shut Off
2 20835 6 CLAMP, Hose
3 50831-55 1 HOSE, 55”
4 50831-50 1 HOSE, 50”
5 50831-36 1 HOSE, 36”
6 50833-51 1 WIRE LOOM, 51”
7 50833-33 1 WIRE LOOM, 33”
8 50833-24 1 WIRE LOOM, 24”
9 1726400 2 RUBBER BUSHING
10 1674231 2 ELBOW FITTING
