Simplicity Colt ZT2148T

14
TP 400-7090-01-CT-D
© Copyright 2004 Ferris Industries. All Rights Reserved.
The above parts group applies to the following Model Nos.:
ZT2148T (S/N 124 & above)
ZT2348T
ZT2352T (S/N 124 & above)
Fuel Supply Hose & Tank Replacement Part Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
Connect to Engine
LH Fuel Tank RH Fuel Tank
3
4
2
5
1
876
Tank
Components
Tank
Components
9
10
11
12
11
13
9
10
11
12
11
13
