12 - 5
12 Mower Deck Repair
30" Mower Deck - Drive & Arbors, Later Models
Ref. Qty. Description Ref. Qty. Description
1 1 V-BELT, 73-7/64"
2 1 WASHER, Spring
3 1 BLADE, Mower, 30"
4 1 GRIP, Lever
5 1 SPRING
6 1 SPACER
7 1 ADAPTER, Arbor
8 1 FITTING, Grease
9 1 IDLER PULLEY, Backside
10 2 BEARING
11 1 GASKET, Foam
12 1 PULLEY ASSY., Idler, Fixed, 6" Dia.
13 1 LEVER ASSY.
14 1 WASHER, Hex
15 1 PULLEY
16 1 SHIELD, Grass, Lower
17 1 COVER, Arbor Housing
18 1 SPACER
19 1 ARBOR HOUSING ASSY. (Incl. Ref. No. 8)
20 1 SHAFT, Arbor, 5-53/64"
21 1 HUB, Pulley, 1-3/16"
22 1 WASHER, Cupped
23 2 WASHER, Belleville
24 1 NUT, Hex, Flange, 9/16-18
25 1 NUT, Hex, 3/8
26 1 LOCKWASHER, 3/8
27 3 WASHER, Flat, 13/32 x 1 x 1/8
28 1 CAPSCREW, Hex, 7/16-14 x 1, Gr. 8
29 1 CAPSCREW, Hex, 3/8-16 x 2
30 1 CAPSCREW, Hex, 3/8-16 x 3
31 2 WASHER, Flat, 3/8 x 1-1/2 x 1/8
32 2 WASHER, Plain, 3/8
33 1 NUT, Hex, Whizlock, 3/8-16
34 1 NUT, Hex, Lock, 3/8-16
35 6 SCREW, Hex, Taptite, 5/16-18 x 1
30" Mower Deck - Drive & Arbors, Later Models
