12 - 9
12 Mower Deck Repair
34" Mower Deck - Drive & Arbors, Early Models
1 4 BEARING
2 1 V-BELT, 82-7/64"
3 1 SPRING
4 2 COVER, Arbor Housing
5 2 WASHER, Spring
6 2 WASHER, Spline
7 1 SPACER
8 2 SHIELD, Grass, Upper
9 12 SCREW, Taptite, 5/16-18 x 3/4
10 1 GRIP, Lever
11 1 SPACER
12 2 COLLAR, Mower Arbor
13 2 SHAFT, Arbor
14 2 SHAFT & BEARING ASSY.,
(Incl. Ref. Nos. 1 & 13)
15 2 SHIELD, Grass, Bottom
16 12 WASHER, Shim
17 2 ARBOR HOUSING ASSY. (Incl. Ref. No. 18)
18 2 FITTING, Grease
19 1 IDLER, Backside
20 2 ADAPTER, Blade
21 1 BLADE, Mower, Small (14-27/64")
22 1 BLADE, Mower, Large (19-3/16")
23 1 PULLEY ASSY., Small Blade
24 1 PULLEY ASSY., Large Blade
25 2 GASKET, Foam
26 1 LEVER ASSY.
27 1 NUT, Hex, 3/8-16
28 2 LOCKWASHER, 3/8
29 2 LOCKWASHER, 7/16
30 1 CAPSCREW, Hex Hd., 3/8-16 x 2-1/2
31 1 CAPSCREW, Hex Hd., 7/16-14 x 1-1/4, Gr. 8
32 2 CAPSCREW, Hex Hd., 7/16-14 x 1, Gr. 8
33 2 WASHER, Flat, 3/8 x 1/8
34 2 WASHER, Flat, 3/8
35 1 CAPSCREW, Hex Hd., 7/16-14 x 2, Gr. 8
36 1 NUT, Hex, 3/8-16
37 1 CAPSCREW, Hex Hd., 3/8-16 x 2-3/4
38 1 NUT, Hex, Flange Lock, 3/8-16
39 2 WASHER
Ref. Qty. Description Ref. Qty. Description
34" Mower Deck - Drive & Arbors -Early Models
