12 - 11
12 Mower Deck Repair
34" Mower Deck - Drive & Arbors, Later Models
34" Mower Deck - Drive & Arbors, Later Models
1 1 V-BELT, 82-7/64"
2 1 SPRING
3 2 WASHER, Spring
4 1 SPACER
5 12 SCREW, Taptite, 5/16-18 x 3/4
6 1 GRIP, Lever
7 1 SPACER
8 2 FITTING, Grease
9 1 PULLEY, Idler, Backside
10 4 BEARING
11 1 BLADE, 14-27/64"
12 1 BLADE, 19-29/32"
13 2 GASKET, Foam
14 1 LEVER ASSY.
15 2 WASHER, Hex
16 1 PULLEY, 3-3/4"
17 1 PULLEY, 5"
18 2 SHIELD, Grass, Lower
19 2 COVER, Arbor Housing Assy.
20 2 SPACER
21 2 ARBOR HOUSING ASSY. (Incl. Ref. No. 8)
22 1 SHAFT, Arbor, 5-53/64"
23 1 SHAFT, Arbor, 6-33/64"
24 1 HUB, Pulley, 1-3/16"
25 1 HUB, Pulley, 1-35/64"
26 2 WASHER
27 4 WASHER, Belleville
28 2 NUT, Hex, Flange, 9/16-18
29 1 NUT, Hex, 3/8-16
30 1 LOCKWASHER, 3/8
31 1 CAPSCREW, 3/8-16 x 2-1/2
32 2 CAPSCREW, Hex, 7/16-14 x 1, Gr. 8
33 2 WASHER, Flat, 3/8
34 2 WASHER, Flat, 3/8
35 1 NUT, Hex, 3/8-16
36 1 CAPSCREW, Hex, 3/8-16 x 2-3/4
37 1 NUT, Hex, Flange, 2-Way, 3/8-16
Ref. Qty. Description Ref. Qty. Description
