12 Mower Deck Repair
34" Mower Deck - Housing, Hitch, & Deflector
44" Mower Deck - Height Adjustment & Rollers
1 1 SPRING
2 2 SPACER
3 1 SPACER
4 1 SPACER
5 1 HOUSING ASSY., 34" (Orange)
1 HOUSING ASSY., 34" (Black)
6 1 ROD, Latch, Hitch
7 1 CLAMP
8 1 SPRING
9 1 DEFLECTOR, Plastic
10 1 ROD, Deflector
11 1 TRUNNION
12 1 ROD, Adjustment
13 1 HITCH ASSY.
14 3 JAMNUT, Hex, 1/2-13
15 2 NUT, Hex, 1/4-20
16 2 LOCKWASHER, 1/4
17 1 WASHER, Flat, 5/16
18 2 LOCKNUT, Hex, 3/8-16
19 2 CAPSCREW, Hex Hd., 3/8-16 x 1-1/4
20 1 CAPSCREW, Hex Hd., 3/8-16 x 1
21 3 WASHER, Flat, 3/8
22 1 NUT, Hex, Flange Lock, 3/8-16
23 2 CARRIAGE BOLT, 1/4-20 x 7/8
24 2 PUSHNUT
25 2 WASHER, Flat, 17/64 x 27/32 x 1/8
26 1 PUSHNUT
Ref. Qty. Description Ref. Qty. Description
