Simplicity Coronet Series

12 - 15
12 Mower Deck Repair
34" Mower Deck - Height Adjustment
34" Mower Deck - Height Adjustment
1 2 RING, Retaining
2 2 BOLT, Shoulder, 3/8-16
3 2 SPACER, Roller
4 2 PIN, Locking
5 7 ROLLER
6 2 NUT, Adjustment
7 2 SPACER
8 1 ARM ASSY.
9 1 SHAFT ASSY., Roller
10 1 COVER, Arbor
11 1 BRACKET, Roller Bar, 34"
12 1 PLATE, Support, RH
13 2 BAR, Mower Transport
14 2 NUT, Hex, 3/8
15 2 LOCKWASHER, 3/8
16 2 LOCKWASHER, 5/16
17 1 NUT, Hex, 5/16-18
18 2 WASHER, Plain, 5/16
19 2 WASHER, Flat, 1/2
20 10 WASHER, Flat, 5/8
21 2 NUT, Flange Lock, 3/8
22 5 SCREW, Taptite, 5/16-18-5/8
23 2 CARRIAGE BOLT, 3/8-16 x 1-1/2
24 2 WASHER, Plain, 21/32 x 1-1/4 x 1/16
25 2 PIN, Retaining
26 2 CARRIAGE BOLT, 5/16-18 x 1-1/4
Ref. Qty. Description Ref. Qty. Description
