1 General Information
Specifications
1 - 13
Lubrication Full Pressure Lube with Oil Filter
Oil Capacity 4 Pints (1.9 L)
Fuel Capacity 2 Gal. (7.57 L)
Muffler Quiet Compact, Low Back Pressure
16 HP Command™ — Kohler
Horsepower
16 HP @ 3600 rpm
Displacement
27.9 Cu. In. (460 cc)
Electrical
12 Volt, 15 Amp Alternator Battery: 200 CCA
Oil Capacity
Oil Capacity 4 Pints (1.9 L)
TRANSMISSION
Gear Models
Type Spur Gear
Material Gear: Powered Metal
Shaft: Hardened
Bearings: Needle Roller and Bushings
Lubrication Bentonite Grease. Transmission is a sealed unit.
Differential Bevel Gear Type
Gear Range Five Forward, One Reverse
Ground Speeds lst: 1.2 MPH (1.9 km/h)
2nd: 2.4 MPH (3.9 km/h)
3rd: 3.5 MPH (5.6 km/h)
4th: 4.4 MPH (7.1 km/h)
5th: 5.6 MPH (9.0 km/h)
Reverse: 2..0 MPH (3.2 km/h)
Hydro Models
Type Hydrostatic
Lubrication Transmission is a Sealed Unit
Differential Bevel Gear Type
Ground Speeds Infinite Forward: 0-5.2 MPH (0-8.4 km/h)
Reverse: 0-2.3 MPH (0-3.7 km/h)
CONTROLS
Steering Full Circle Steering Wheel
System Gear and Sector
Clutch/Brake Location Right Front
Pedal Combination Clutch/Brake Pedal
Parking Brake Dash Lock Finger Release
Ground Speed Dash Mounted
Shift Lever
Throttle Control Combination Speed & Choke Control on right side
of seat deck
Key Switch Starter and Magneto ON/OFF Switch located on
left side of seat deck
Mower Drive Electric Clutch PTO Switch located on right side of
seat deck
Mower Cutting Infinite Height Control on Steering Column
Height
CHASSIS
Frame Heavy Gauge , Deep Drawn Steel
Front Axle Self-Leveling Quick Hitch
Seat Deck Lightweight Polymer Alloy
Seat Molded Type with Foam Cushion and Spring
Construction
Front Wheels Tire Size 13 x 5.00-6
Pneumatic Inflation Pressure 10 -12 psi
(68 - 82 kPa)
Rear Wheels Tire Size 16 x 6.50-8
Pneumatic Inflation Pressure 10 -12 psi
(82 - 103 kPa)
Accessibility Seat Deck Tips Forward
Seat Type Bucket, High Back, Adjustable w/
Spring Suspension, Fore and Aft Adjustable
Fuel Tank Material: Non-Corrosive Polyethylene Alloy
Capacity: 2 Gallons (7.5 L)
Turning Radius Inside Rear Tire 12 In. (30.2 cm)
DIMENSIONS
Rider
Overall Length 61 In. (155 cm)
Overall Width
- w/30 mower 38.5 In. (97.8 cm)
- w/34 mower 45.5 In. (115.6 cm)
- at rear wheels 33 In. (83.8 cm)
Height at
- steering wheel 41 In. (104.1 cm)
- seat back 35 In. (88.9 cm)
- engine cover 28 In. (71.1 cm)
Wheel Base 43 In. (109.2 cm)
Weight (approx.)
- 8.5 HP w/30”mower Net: 410 lbs. (183 kg)
Shipping: 535 Ibs. (241 kg)
- 12 HP w/30”mower Net: 410 lbs. (183 kg)
Shipping: 535 Ibs. (241 kg)
- 12 HP w/34”mower Net: 446 lbs. (183 kg)
Shipping: 571 Ibs. (241 kg)
- 13 HP w/34”mower Net: 446 lbs. (183 kg)
Shipping: 571 Ibs. (241 kg)
Mower
Type: 30” Single Blade
34” Dual Blade
Height of Cut 1.0 - 3.75 In. (2.45- 9.53 cm)
Cutting Positions Infinite
Level Adjustments Side-to-Side & Front-to-Back
Spindles Sealed Ball Bearings w/Lube Fitting
Blade Mounting Center Bolt With Spring Washer
Discharge Deflector Hinged with Spring Positioning
Mounting At Front Axle - Quick Hitch
with Auto-Leveler TM
