7 - 5
7 Foot Controls Repair
Foot Controls Diagram - Hydro Models
1 SPRING, Return
2 A/R WASHER, 3/4
3 1 SPRING
4 1 PULLEY, Idler
5 1 SPACER, 25/64 x 5/8 x 11/16
6 1 KLIPRING, 1/2
7 1 SPACER
8 1 PAD, Pedal
9 1 ROD, Clutch, Front
10 1 LEVER, Clutch
11 1 GUARD, Spring
12 1 TORSION BAR
13 2 BRACKET, Torsion Bar
14 1 PIVOT, Brake
15 1 KLIP RING, 3/4
16 1 SPRING, Compression
17 1 ROD, Return, Front
18 1 ROD, Clutch, Rear
19 2 CLEVIS, Idler Bracket
20 1 PLATE
21 1 ROD, Control
22 1 ROD, Brake
23 1 LEVER, Control
24 1 SPACER
25 1 ROD, Shift, Front
26 1 PIVOT SHAFT ASSY.
27 1 ROD, Return, Rear
28 1 SPACER, Pivot
29 1 TUBE
30 2 LOCKWASHER, 5/16
31 1 LOCKWASHER, 5/16
32 2 NUT, Hex, 5/16-18
33 1 NUT, Hex, 5/16-18
34 6 COTTER PIN, 7/64 x 3/4
35 3 WASHER, Plain
36 1 WASHER, Plain
37 2 WASHER, Plain, 5/16
38 2 NUT, Hex, Lock, 5/16-18
39 1 CAPSCREW, 5/16-18 x 1-3/4
40 1 CAPSCREW, Hex, 1/4-20 x 3/4
41 2 WASHER, Plain, 1/2 x 1 x 1/32
42 1 WASHER, Plain
43 4 SCREW, Taptite, 5/16-18 x 1/2
44 1 WASHER, Plain, 13/32 x 7/8 x 5/64
45 1 SCREW, Taptite, 1/4-20 x 5/8
46 3 NUT, Hex, Flange Whiz, 1/4-20
47 1 CARRIAGE BOLT, 1/4-20 x 7/8
48 1 CARRIAGE BOLT, 5/16-18 x 1
49 1 CARRIAGE BOLT, 5/15-18 x 2-3/4
50 1 CARRIAGE BOLT, 3/8-16 x 2-/1/4
51 1 CARRIAGE BOLT, 5/16-18 X 1-1/4
52 1 NUT, Hex, Jam, Lock, 3/8-16
53 2 KEY
Ref. Qty. Description Ref. Qty. Description
Foot Controls - Hydro Models
