9
TP 400-2307-03-LW-S
Handles and Controls Group
50 1918452 2 PIN, Cotter
51 1918447 2 PIN, Cotter
52 1666255 1 ROD, Shift, 3/8 15 5/16
53 1916964 3 LOCKWASHER, Spring, 1/4
54 1916622 3 NUT, Hex, 1/2-20
55 1720238 1 ROD, Upper Shift, 12 1/2 Long
56 1921159 1 CAPSCREW, Hex Head, 1/4-20 x 2 1/4
57 1668523 1 ROD & CLEVIS ASSEMBLY, Shift
58 1668524 2 BLOCK, Pivot, 3/4 x 3/4
59 1924361 1 WASHER, 1/2
60 1668185 2 BUSHING, 1/2
61 1720240 1 ROD & ARM ASSEMBLY, Pivot
62 1715123 1 SPRING, Torsion, 1/2 Long
63 172038 1 KNOB
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693984 860M, 8HP Manual Start
1693985 860M, 8HP Manual Start (Export)
1694242 860E, 8HP Electric Start
