Simplicity HMSK110 - Wheels and Tires Group - 1180 & 1390

76
TP 400-2307-03-LW-S
Wheels & Tires Group - 1180 & 1390
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
W985879
7
9
10
5
5
3
4
3
1
2
6
8
The above parts group applies to the following Mfg. Nos.:
1693656 1180M, 11HP Manual Start
1693657 1180M, 11HP Manual Start (Export)
1694244 1180E, 11HP Electricl Start
© Copyright 2002 Simplicity Manufacturing, Inc. All Rights Reserved.
