77
TP 400-2307-03-LW-S
Wheels & Tires Group - 1180 & 1390
1 1921978 1 CAPSCREW, Hex Head, 5/16-18 x 2
2 1919438 1 NUT, Hex Lock ESNA Light, 5/16-18
3 172353 2 VALVE STEM & CAP
4 1722762 1 HUB, Wheel, RH
5 1722597 2 TIRE, 16 x 6.50-6
6 1722599 1 WHEEL & TIRE ASSEMBLY, RH (Includes Ref. Nos. 3, 4 & 5)
7 1722761 1 HUB, Wheel, LH
8 1722598 1 WHEEL & TIRE ASSEMBLY, LH (Includes Ref. Nos. 3, 5 & 7 )
9 153038 2 TUBE, Tire
10 1666969 1 KLIK-PIN
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693656 1180M, 11HP Manual Start
1693657 1180M, 11HP Manual Start (Export)
1694244 1180E, 11HP Electricl Start
