75
TP 400-2307-03-LW-S
Wheels & Tires Group - 860DLX & 970
1 1921978 1 CAPSCREW, Hex Head, 5/16-18 x 2
2 1919438 1 NUT, Hex Lock ESNA Light, 5/16-18
3 172353 2 VALVE STEM & CAP
4 1714242 1 HUB, Wheel, RH
5 1612000 2 TIRE, 4.80-4.00-8
6 1714235 1 WHEEL & TIRE ASSEMBLY, RH (Includes Ref. Nos. 3, 4 & 5)
7 1720307 1 HUB, Wheel, LH
8 1720306 1 WHEEL & TIRE ASSEMBLY, LH (Includes Ref. Nos. 3, 5 & 7)
9 153038 2 TUBE, Tire
10 1666969 1 KLIK-PIN
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693652 860DLX, 8HP Manual Start
1693653 860DLX, 8HP Manual Start (Export)
1694241 860DLXE, 8HP Electric Start
1693654 970M, 9HP Manual Start
1693655 970M, 9HP Manual Start (Export)
1694243 970E, 9HP Electricl Start
