27
TP 400-2307-03-LW-S
Engine & Frame Group - 8HP, Electric Start
49 1702979 1 SPRING, Compression
50 ** 1 WICK, Oil
51 1702017 1 PULLEY, Drive
52 1701776 1 PULLEY, Drive
53 1922755 1 WASHER,13/32 x 1
54 1916965 1 LOCKWASHER, Spring, 3/8
55 1960345 1 CAPSCREW, Hex Head, 3/8-24 x 2
56 1701011 1 TIE, Self Locking
57 1924940 3 WASHER, Flat,13/32
58 157081 1 SPACER
59 1717432 1 CORD, Electric, 3 Prong
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* See your local Tecumseh distributor for Parts and Service.
** Not a Service Part.
The above parts group applies to the following Mfg. Nos.:
1694241 860DLXE, 8HP Electric Start
